We cannot verify this setup because its operating clearances have not been measured. Product dimensions alone cannot answer whether it works in the space.
Touchscreen all-in-one on an open counter
- You must buy
- $0 – $0
- Optional adds
- $50 – $150
- Space
- Open counter
- The Knock Box 20 editorial band, drawn but not stated - no checked price stands behind it
- 20 oz Latte Art Pitcher, Etched Graduations editorial band, drawn but not stated - no checked price stands behind it
Excluded from every bar because no band exists: Barista Touch Espresso Machine (BES880), Oracle Touch Espresso Machine (BES990). They are not drawn as zero.
No required item carries a band, so what you must buy cannot be totalled. No item on these bars has a checked price, so every length is a band and no bar is a quote. Excluded from every bar because no band exists: Barista Touch Espresso Machine (BES880), Oracle Touch Espresso Machine (BES990).Figures are editorial budget bands, not live prices. A band is a range, so a build has a cheapest and a dearest version and both are shown.
Will it fit your space?
Not established- Width available
- 1200 mm
- Depth available
- 600 mm
- Height available
- unconstrained
the bar under the plan is 200 mm. Station drawn at 1200 × 600 mm.
- Barista Touch Espresso Machine (BES880)399 × 320 mmmanufacturer figure, not measured by us
operating clearance not established. Not one clearance figure exists for any item in this setup, so the region around each drawn item has no size, is not to scale, and cannot be measured against the bar. Where the plan is drawn is a packing illustration, not a recorded layout.
at most 801 mm of width left over: 1200 mm available less 399 mm of recorded envelope. Arithmetic on recorded envelopes only - no clearance is subtracted.
Open counter drawn to scale at 1200 by 600 millimetres. 1 item drawn from recorded envelopes: Barista Touch Espresso Machine (BES880) 399 by 320 millimetres. Operating clearance is not established for any item, so the region around each one is drawn without a committed size and cannot be measured. At most 801 millimetres of width is left over: 1200 available less 399 of recorded envelope, with no clearance subtracted.Product dimensions only - operating clearance not established
We hold the manufacturer's product dimensions for part of this setup, but a product envelope is not an operating requirement - it says nothing about the room needed to lift a water tank out, swing a portafilter or load a hopper. Until those are measured, this answer stays open rather than being estimated from the box figures.
- clearance above
Evidence on record: 3 of 6 fields.
Can you refill it where it stands?
- Barista Touch Espresso Machine (BES880)Tank is removed from the rear.manufacturer manual
- Oracle Touch Espresso Machine (BES990)Tank is removed from the rear.manufacturer manual
Will your circuit take it?
- US 15A shared kitchen circuitOver the continuous limit
- 12 Acontinuous
- 15 Abreaker
- 14 Adrawn
1 A of headroom under the 15 A breaker · over the 12 A continuous limit
US 15A shared kitchen circuit: about 14 amps drawn. Under the 15 amp breaker, with 1 amps of headroom. Over the 12 amp continuous limit.Over the continuous limit of a 15A circuit
About 14A against a 12A continuous limit and a 15A breaker. An espresso shot is not a continuous load, so this is not automatically a fault - but only 1A remains for anything else sharing the circuit.
- US 20A shared kitchen circuitLikely fit
- 16 Acontinuous
- 20 Abreaker
- 14 Adrawn
6 A of headroom under the 20 A breaker · under the 16 A continuous limit
US 20A shared kitchen circuit: about 14 amps drawn. Under the 20 amp breaker, with 6 amps of headroom. Under the 16 amp continuous limit.Fits a 20A circuit
About 14A, leaving 6A of headroom for anything else on the same circuit.
- US 20A dedicated circuitLikely fit
- 16 Acontinuous
- 20 Abreaker
- 14 Adrawn
6 A of headroom under the 20 A breaker · under the 16 A continuous limit
US 20A dedicated circuit: about 14 amps drawn. Under the 20 amp breaker, with 6 amps of headroom. Under the 16 amp continuous limit.Fits a 20A circuit
About 14A, leaving 6A of headroom. The draw is computed from a published rating, not from a meter reading we took, so this is a likely fit rather than a verified one.
Judged as a US 120V circuit under the US continuous-load rule (80% of the breaker rating).
Draw is computed from the manufacturer's own rating plate. The breaker figure is what trips when everything runs at once; the continuous figure is the code limit for a load running three hours or more, which an espresso shot is not. Both are shown rather than one, because collapsing them would either overstate or understate the risk.
What the setup contains
- Barista Touch Espresso Machine (BES880)Grinder
- The Knock Box 20Accessoryup to 20 pucks per the manufacturer
- 20 oz Latte Art Pitcher, Etched GraduationsAccessory
- Oracle Touch Espresso Machine (BES990)Grinderautomatic tamping and frothing per the manual; the larger of the two
What this check cannot see
Space is judged against the station's stated width, depth and height, using each product's envelope and whatever operating clearances are on record. The check does not see an obstacle inside that gap - a cabinet overhang, a wall bracket, a splashback lip - or anything you keep on the counter that is not part of this setup.
Electrical load is the sum of the products declared here against one circuit profile. It does not see other appliances on the same circuit that this setup does not declare, the condition of your wiring, or a supply outside the regime the circuit names.
Pairings are recorded one by one. A pairing that is not recorded reads Not established, which is not a finding that it works and not a finding that it does not.
What we hold, and where it came from
| Measurement | 20 oz Latte Art Pitcher, Etched Graduations | The Knock Box 20 | Barista Touch Espresso Machine (BES880) | Oracle Touch Espresso Machine (BES990) |
|---|---|---|---|---|
| width | Not established | 163 mm manufacturersource | 399 mm manufacturersource | 411 mm manufacturersource |
| depth | Not established | 160 mm manufacturersource | 320 mm manufacturersource | 386 mm manufacturersource |
| height | Not established | 160 mm manufacturersource | 315 mm manufacturersource | 366 mm manufacturersource |
| clearance above | Not established | Not established | Not established | Not established |
| tank-removal clearance | Not established | Not established | Not established | Not established |
| rear clearance | Not established | Not established | Not established | Not established |
